Klaro Retrofitting up to 5,000 inhabitants for concrete tanks (onsite concrete)
Special requirements
Systems for more than 50 inhabitants work on the same principle as small wastewater treatment systems and use the SBR process. Because of the special requirements involved, all systems for more than 50 inhabitants are planned as individual projects. Our experienced team of engineers and technicians will help you to plan your project. We take all local circumstances into account from the concept planning phase to implementation.
Checklist
To plan your system, we need the following information:
- What type of project? (Domestic, hotel, commercial etc.)
- How many people will use the system and what is the water consumption per head?
- What legal requirements apply to wastewater at the location?
- Local power grid
Technical Components
In systems for over 50 inhabitants, the technical components are securely housed in the control cabinet or a plant room. The standard technical components of a wastewater treatment system include:
- Air compressor
- Magnetic distributor manifold
- Microprocessor controller
- Cooling fan
- Main switch
Additional technical components
The modular design of our treatment technology allows various additional components to be added at any time. These include:
- Dosing technology (e.g. for phosphate precipitation)
- UV hygiene module (Disinfection)
- Warning lights
- Soundproof hood for air compressor
- Remote monitoring
Sizing
| max. inhabitants | Depth [mm] | Total volume [l] | Nominal power [kW] | order no. | add to enquiry |
|---|---|---|---|---|---|
| 100 | 2500 | - | - | on request | |
| 200 | 2750 | 83000 | 2'4 | on request | |
| 300 | 300 | 126000 | 4'0 | on request | |
| 400 | 3000 | 162000 | 7'8 | on request | |
| 500 | 3000 | 211000 | 7'8 | on request | |
| 600 | 3000 | 241000 | 2X4'0 | on request | |
| 700 | 3000 | 273000 | 2X4'0 | on request | |
| 800 | 3000 | 313000 | 2x7'8 | on request | |
| 900 | 3000 | 350000 | 2x7'8 | on request | |
| 1000 | 3000 | 400000 | 2x7'8 | on request |
calculated size Request for information
