oneAdvanced domestic wastewater solutions 10 – 90 PE (1,500 – 13,500 l/day)
A reliable wastewater disposal system no longer needs to be complicated. With oneAdvanced domestic, you will be able to take responsibility for the timely disposal of your waste water, while taking care of your budget and the environment.
oneAdvanced domestic dispenses with the unnecessary extras, making it a reliable solution:
- Less energy consumption and less wear
- No mechanical elements in the waste water
- No pumps in the waste water
- No electrical components in the waste water
oneAdvanced domestic is a clean solution
- oneAdvanced domestic only needs 3 steps to produce clear water
- oneAdvanced domestic already meets the needs of tomorrow
oneAdvanced domestic is excellent value for money
- Minimum maintenance costs
- Minimum power consumption
oneAdvanced domestic offers maximum safety and reliability
- Low space requirements
- Long warranty and lifetime
- Twice the buffer volume
- Logistical advantages
Scope of supply: Carat S underground tanks, tank domes, telescopic dome shafts 600, oneAdvanced system pack.
Please order the air hoses separately!
Advantages
Thought-out in every detail
PP control cabinet including new control system. Click here for more information.
The optional outdoor cabinet made of plastic ensures easy access for the maintenance technician even without an appointment. Also an optimal solution for large distances (>20m) between the system and the house.
The inflowing water is directly aerated and thus supplied with oxygen. In this way, biological purification of the water begins immediately.
PP control cabinet including new control system. Click here for more information.
The optional outdoor cabinet made of plastic ensures easy access for the maintenance technician even without an appointment. Also an optimal solution for large distances (>20m) between the system and the house.
The inflowing water is directly aerated and thus supplied with oxygen. In this way, biological purification of the water begins immediately.
Significantly lower energy consumption due to only one conveying process. In addition, energy-saving stepper motors are used instead of solenoid valves.
Sizing
| Inh. | max. daily flow [l/d] | Set consisting of: | Volume [l] | Length [mm] | Width [mm] | Height [mm] | Weight [kg] | order no. | add to enquiry |
|---|---|---|---|---|---|---|---|---|---|
| 8-10 | 1500 | 1x4800 | 4800 | 2280 | 1985 | 2110 | 185 | 106572 | |
| 10-14 | 2100 | 1x6500 | 6500 | 2390 | 2190 | 2390 | 220 | 106841 | |
| 12-16 | 2400 | 2x3750 | 7500 | 2280 | 1755 | 1880 | 150 | 106847 | |
| 16-22 | 3300 | 2x4800 | 9600 | 5160 | 1985 | 2430 | 185 | 106931 | |
| 20-28 | 4200 | 2x6500 | 13000 | 5380 | 2190 | 2710 | 220 | 106943 | |
| 25-32 | 4800 | 4x3750 | 15000 | 11000 | 1800 | 2200 | 300 | 106949 | |
| 32-44 | 6600 | 4x4800 | 19200 | 11000 | 2000 | 2430 | 370 | 106952 | |
| 42-50 | 7500 | 4x6500 | 26000 | 11360 | 2200 | 2710 | 1060 | 106955 | |
| 51-60 | 9000 | 4x6500 | 26000 | 11360 | 2200 | 2710 | 1060 | 372710 | |
| 61-90 | 13500 | 5x6500 | 32500 | 8370 | 5000 | 2710 | 1325 | 372711 |
calculated size Request for information
