KLAROMAX Retrofitting systems for concrete tanks from 1,000 PE (150,000 l/d) upwards
Customised solution for the efficent treatment of large volumes of wastewater
Specially designed for applications with a daily wastewater volume of 150 m³ or more per day, the KLAROMAX wastewater treatment plant is a reliable solution for a wide variety of locations worldwide.
Our experienced team of engineers and technicians will help you to plan your project. We take all local circumstances into account from the concept planning phase to implementation.
Checklist
To plan your system, we need the following information:
- What type of project? (Domestic, hotel, commercial etc.)
- How many people will use the system and what is the water consumption per head?
- What legal requirements apply to wastewater at the location?
- Local power grid
Technical Components
In systems for over 50 inhabitants, the technical components are securely housed in the control cabinet or a plant room. The standard technical components of a wastewater treatment system include:
- Air compressor
- Magnetic distributor manifold
- Microprocessor controller
- Cooling fan
- Main switch
Additional technical components
The modular design of our treatment technology allows various additional components to be added at any time. These include:
- Dosing technology (e.g. for phosphate precipitation)
- UV hygiene module (Disinfection)
- Warning lights
- Soundproof hood for air compressor
- Remote monitoring
Sizing
| max. inhabitants | Depth [mm] | Total volume [l] | Nominal power [kW] | order no. | add to enquiry |
|---|---|---|---|---|---|
| 100 | 2500 | - | - | on request | |
| 200 | 2750 | 83000 | 2'4 | on request | |
| 300 | 300 | 126000 | 4'0 | on request | |
| 400 | 3000 | 162000 | 7'8 | on request | |
| 500 | 3000 | 211000 | 7'8 | on request | |
| 600 | 3000 | 241000 | 2X4'0 | on request | |
| 700 | 3000 | 273000 | 2X4'0 | on request | |
| 800 | 3000 | 313000 | 2x7'8 | on request | |
| 900 | 3000 | 350000 | 2x7'8 | on request | |
| 1000 | 3000 | 400000 | 2x7'8 | on request |
calculated size Request for information
